Official Gene Symbol | Other Aliases |
---|---|
MAP2K7 | JNKK2, MEK7, MKK7, PRKMK7, SKK4 |
Sequence Length (AA) | Molecular Weight (Da) |
---|---|
419 | 47485 |
Protein Name |
---|
Dual specificity mitogen-activated protein kinase kinase 7 |
Sources | |
---|---|
UniProt PhosphoSitePlus ® GeneCards |
Human Protein Atlas |
10 | 20 | 30 | 40 | 50 |
MAASSLEQKL | SRLEAKLKQE | NREARRRIDL | NLDISPQRPR | PTLQLPLAND |
60 | 70 | 80 | 90 | 100 |
GGSRSPSSES | SPQHPTPPAR | PRHMLGLPST | LFTPRSMESI | EIDQKLQEIM |
110 | 120 | 130 | 140 | 150 |
KQTGYLTIGG | QRYQAEINDL | ENLGEMGSGT | CGQVWKMRFR | KTGHVIAVKQ |
160 | 170 | 180 | 190 | 200 |
MRRSGNKEEN | KRILMDLDVV | LKSHDCPYIV | QCFGTFITNT | DVFIAMELMG |
210 | 220 | 230 | 240 | 250 |
TCAEKLKKRM | QGPIPERILG | KMTVAIVKAL | YYLKEKHGVI | HRDVKPSNIL |
260 | 270 | 280 | 290 | 300 |
LDERGQIKLC | DFGISGRLVD | SKAKTRSAGC | AAYMAPERID | PPDPTKPDYD |
310 | 320 | 330 | 340 | 350 |
IRADVWSLGI | SLVELATGQF | PYKNCKTDFE | VLTKVLQEEP | PLLPGHMGFS |
360 | 370 | 380 | 390 | 400 |
GDFQSFVKDC | LTKDHRKRPK | YNKLLEHSFI | KRYETLEVDV | ASWFKDVMAK |
410 | 419 | |||
TESPRTSGVL | SQPHLPFFR |
Data source: UniProt
Uniprot Database Entry PhosphoSitePlus ®
loading
Data source: Panorama
Data source: Panorama
Data source: Panorama
Data source: Panorama
Retrieving Data
Data source: Panorama
Average intra-assay CV (within day CV) |
Average inter-assay CV (between day CV) |
Total CV |
n= | |||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
Fragment ion / Transition | Low | Med | High | Low | Med | High | Low | Med | High | Low | Med | High |
y5 (1+) | 5.7 | 3.6 | 6 | 9.7 | 5.4 | 6.1 | 11.3 | 6.5 | 8.6 | 15 | 15 | 15 |
y4 (1+) | 7 | 4.2 | 4.8 | 10.1 | 6.1 | 4.8 | 12.3 | 7.4 | 6.8 | 15 | 15 | 15 |
b6 (1+) | 6.4 | 4.1 | 6.2 | 9.1 | 6.3 | 6.7 | 11.1 | 7.5 | 9.1 | 15 | 15 | 15 |
sum | 6.2 | 3.9 | 5.5 | 9.4 | 5.9 | 5.5 | 11.3 | 7.1 | 7.8 | 15 | 15 | 15 |
Data source: Panorama
Data source: Panorama
Data source: Panorama
Data source: Panorama
Retrieving Data
Data source: Panorama
Average intra-assay CV (within day CV) |
Average inter-assay CV (between day CV) |
Total CV |
n= | |||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
Fragment ion / Transition | Low | Med | High | Low | Med | High | Low | Med | High | Low | Med | High |
y6 (2+) | 3.5 | 9.4 | 8.1 | 3.6 | 10.3 | 12.2 | 5 | 13.9 | 14.6 | 15 | 14 | 15 |
y8 (2+) | 3.4 | 6.5 | 6.5 | 3.7 | 7.6 | 10 | 5 | 10 | 11.9 | 15 | 14 | 15 |
y13 (2+) | 4.3 | 28.5 | 7.5 | 4.5 | 45.6 | 11.6 | 6.2 | 53.8 | 13.8 | 15 | 14 | 15 |
sum | 2.9 | 7.2 | 7 | 3 | 8.2 | 11 | 4.2 | 10.9 | 13 | 15 | 14 | 15 |
Data source: Panorama
Data source: Panorama
Data source: Panorama
Data source: Panorama
Retrieving Data
Data source: Panorama
Average intra-assay CV (within day CV) |
Average inter-assay CV (between day CV) |
Total CV |
n= | |||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
Fragment ion / Transition | Low | Med | High | Low | Med | High | Low | Med | High | Low | Med | High |
y3 (1+) | 19.4 | 14.2 | 10.3 | 19.7 | 13.2 | 12.6 | 27.6 | 19.4 | 16.3 | 15 | 15 | 15 |
y4 (1+) | 11.4 | 8.6 | 5.9 | 14 | 8.9 | 7.8 | 18.1 | 12.4 | 9.8 | 15 | 15 | 15 |
y5 (1+) | 9.4 | 7.9 | 6.1 | 9.9 | 7.9 | 8.4 | 13.7 | 11.2 | 10.4 | 15 | 15 | 15 |
b6 (1+) | 10.6 | 9 | 7.9 | 14.7 | 8.4 | 6.6 | 18.1 | 12.3 | 10.3 | 15 | 15 | 15 |
b5 (1+) | 14.6 | 6.6 | 10.1 | 17.9 | 4 | 10.8 | 23.1 | 7.7 | 14.8 | 15 | 15 | 15 |
b4 (1+) | 13.9 | 9.4 | 6.6 | 12.2 | 9.7 | 7.8 | 18.5 | 13.5 | 10.2 | 15 | 15 | 15 |
b3 (1+) | 7.1 | 5.6 | 3.9 | 8.2 | 6.4 | 4.1 | 10.8 | 8.5 | 5.7 | 15 | 15 | 15 |
sum | 4.8 | 4.6 | 3 | 6.2 | 4.4 | 4.1 | 7.8 | 6.4 | 5.1 | 15 | 15 | 15 |
Data source: Panorama
Data source: Panorama
Data source: Panorama
Data source: Panorama
Retrieving Data
Data source: Panorama
Average intra-assay CV (within day CV) |
Average inter-assay CV (between day CV) |
Total CV |
n= | |||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
Fragment ion / Transition | Low | Med | High | Low | Med | High | Low | Med | High | Low | Med | High |
y4 (1+) | 4.5 | 2.4 | 3.5 | 5.7 | 2.6 | 4.1 | 7.3 | 3.5 | 5.4 | 15 | 15 | 15 |
y5 (1+) | 8.4 | 3.7 | 3.9 | 8.8 | 4.4 | 4.2 | 12.2 | 5.7 | 5.7 | 15 | 15 | 15 |
y6 (1+) | 10.6 | 5.9 | 4 | 10.3 | 5.8 | 5.1 | 14.8 | 8.3 | 6.5 | 15 | 15 | 15 |
y7 (1+) | 4.2 | 3.4 | 2.6 | 4.9 | 4.3 | 3.5 | 6.5 | 5.5 | 4.4 | 15 | 15 | 15 |
y9 (1+) | 7.7 | 6.2 | 4.5 | 9.5 | 7 | 5.6 | 12.2 | 9.4 | 7.2 | 15 | 15 | 15 |
sum | 2.7 | 1.7 | 1.9 | 3.8 | 2.4 | 2.9 | 4.7 | 2.9 | 3.5 | 15 | 15 | 15 |
